6230 Thermal Transfer Overprinting (TTO)

FEATURES

Printhead

32mm, 200 dpi (8 dots/mm)

Print Area

Continuous mode: Max. 32mm x 100mm (1.26” x 3.93”)

Intermittent mode: Max. 32mm x 47mm (1.26” x 1.85”)

Printing Modes

Continuous & Intermittent modes in the same machine

Print Speed

Intermittent: 50mm/sec. to 300mm/sec. (2.0”/sec to 11.8”/sec)

Continuous: 40mm/sec. to 500mm/sec. (1.6”/sec to 19.7”/sec)

Operator Interface

5.0” Color QVGA CSTN LCD and touch screen (800 x 480 pixels)
WYSIWYG print preview
On-board diagnostics
3 levels of password protection
Multiple language support

Ribbon Drive

Solid-state, clutchless bi-directional ribbon drive, including

Ribbon break detection
End of reel detection
Ribbon consumption indication
Ribbon Saving Mode: Radial

Printing Capabilities

Full downloadable font support using Windows TrueType fonts

Fixed and variable text and numeric data

User entered text and numeric data (including Chinese)

Flexible date / time formats (based on internal real time clock)

Auto best before date calculations

Flexible shift code formats

Bar Codes

EAN8, EAN13, UPCA, UPCE and QR codes

Ribbon Length

700 meters (766 yds.) maximum, available in variety of grades and colors

Ribbon Widths

0.8” (20mm) min, 1.3” (33mm) max

Image Management

Design

Videojet CLARiSOFT CLARiSUITE or VideojetConnect Design Template
Management software

Storage

Internal memory 30 MB, expandable to 4GB

Message upload

USB memory stick
Ethernet
RS232Videojet 6230 App* via Bluetooth**

Network Management Software

CLARiNET

Remote Coder Conﬁguration Software

CLARiTY Conﬁguration Manager (included)

External Communications

USB memory stick, ethernet, RS232, ASCII and binary communications

External Inputs

Print Go
Inhibit Print
Encoder (single phase or quadrature)

External Outputs

Fault
Warning
Busy
Printing

Standard installation options leader/follower conﬁguration

Up to four Videojet 6230 printers controlled via a single CLARiTY control unit

Power Supply

100-240 VAC, 50/60Hz, 24V (120W) 5A

Operating Temperature

32°-104°F (0°- 40° C)

Printer body

* The Videojet 6230 app supports Android OS, Version 4.4.4 (KitKat) or higher. The Android phone is required to allow Bluetooth tethering when using the Videojet 6230 App.

**A Bluetooth USB Adapter is required when using the Videojet 6230 App. The Videojet 6230 printer is warranted to work only with the recommended Videojet supplied Bluetooth USB Adaptors that comply with the applicable FCC or CE regulations. Please check with your local authorities to determine if additional country-speciﬁc certiﬁcation is required for your country.

6230
