1280

CIJ

FEATURES

Line speed capability

Can print 1 to 5 lines of print at speeds of up to 889fpm (271mpm) (10 characters per inch, single line of print)

Font matrix configuration

Single-line: 5×5, 5×7, 7×9, 9×12, 10×16, 16×24, 25×34
Twin-line: 5×5, 5×7, 7×9, 9×12, 10×16
Tri-line: 5×5, 5×7, 7×9
Quad-line: 5×5, 5×7
Five-line: 5×5

Linear bar codes

UPC A&E; EAN 8 & 13; Code 128 A, B & C; UCC/EAN 128;
Code 39; Interleaved 2 of 5; GS1

QR codes

21×21, 25×25, 29×29, 33×33
Error correction mode L, M, Q or H

DataMatrix codes

Square Form up to 32×32; Rectangular Form up to 16×48

Nominal character height

Selectable from 0.079” (2mm) to 0.40” (10mm), depending on font

Throw distance

Optimal: 0.472” (12mm)
Range: 0.197” (5mm) to 0.591” (15mm)

Nominal character height

Selectable from 0.079” (2mm) to 0.40” (10mm), depending on font

Throw distance

Optimal: 0.472” (12mm)
Range: 0.197” (5mm) to 0.591” (15mm)

User interface

8” high-response TFT-LCD touch screen
WYSIWYG touch to edit message editing

Custom logo/graphics

Can be created via optional CLARiSOFTTM software*

Character sets

Chinese, Russian/Bulgarian, Turkish/Scandinavian, Romanian, Greek, Arabic, Japanese/Kanji, Faroese, Hebrew, Icelandic, Korean, East European, European/American and Vietnamese

Languages and interface options

English, Arabic, Bulgarian, Czech, Danish, Dutch, Finnish, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Serbian, Simple Chinese, Spanish, Swedish, Thai, Traditional Chinese, Turkish and Vietnamese

Input/output

Product detect input
Encoder input
Beacon (Alarm light) output
Relay output
USB 2.0 (2x)
Ethernet LAN™

Message storage

More than 250 complex messages

Environmental protection

IP55 standard, no plant air required, stainless steel cabinet

Printhead

Heated printhead
Diameter: 1.63” (41.3mm)
Length: 10.62” (269.8mm)

Printhead umbilical

Ultra flexible
Length: 6.56’ (2m)
Diameter: 0.91” (23mm)
Bend radius: 4.0” (101.6mm)

Fluids containers

Ink and Make-up Smart Cartridge™ 0.793 qt. (750ml)

Temperature/humidity range

32°F to 122°F (0°C to 50°C)
0% to 90% RH non-condensing
With selected inks; actual installation may require additional hardware based on production environment conditions

Electrical requirements

Nominal supply power 100-240 VAC at 50/60 Hz, 70W

Approximate weight

Unpacked and dry: 39.5lbs (17.9kg)

Options

Dry air kit for high humidity and harsh environments (requires plant air)
Wide range of accessories

Printer body
