2380

Print Speed

Bar code printing – 0.6 to 66mpm (2.0 to 216ft/min.)

Alphanumeric text – up to 132mpm (433ft/min.)

Speeds are density dependent

Print Distance

0.5mm to 4.0mm max. (0.02 – 0.15”)

Print Area (per printhead)

70mm (H) x 2000mm (L) (2.8” x 78”), 180 dpi

Bar Codes

UPC A&E; EAN 8 & 13; Code 128 A, B & C; UCC/EAN 128; Code 39; Interleaved 2 of 5;

RSS/GS1 Databar (including 2D composite codes); DataMatrix; QR codes

User Interface

8″ high-response TFT-LCD touch screen
WYSIWYG touch to edit message editing
On-board diagnostics

Graphics, Images and Logos

Can be created via optional CLARiSOFTTM software

Printing Capabilities

Full downloadable font support using TrueType® fonts (including multiple languages and Unicode support); fixed, variable and merged text fields; flexible date/time formats; flexible shift code formats; auto best before date calculations and concession management; calendar rules; auto incrementing decrementing text, counters and bar codes; multiple graphic formats supported (up to maximum print area); link fields to databases; scalable
text and text blocks

Languages

English, Arabic, Bulgarian, Chinese (Mandarin), Czech, Danish, Dutch, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Thai, Turkish and Vietnamese

On-Board Memory

8 GB memory

Inputs / Outputs

1 product detect input, 1 DB15 interface integrated shaft encoder input, job select inputs, 24VDC output, 3 configurable inputs and outputs for driving relay control or beacon
1 DB9 interface for sharing product detect and encoder signal between printers
1 USB 2.0 host

Supported Field Types

Fixed, variable (user entered), merged, database, counters, date, offsets, time, paragraph (Text Blocks)
Basic shape drawing (circles, rectangles etc.)

External Communications

Binary and ASCII comms protocols
Host PC mode (Remote Database) using CLARiNETTM
Zebra (ZPL) protocol
USB connectivity for job download and software update

Connectivity Options

RS232, dual Ethernet and Wi-Fi

Operation Modes

Single printhead in standard mode, two printheads in leader/follower mode

Network Control Software

CLARiNET™ network management software

Ink/Ink System

Non-pressurized, screw-in canister; 175ml or 365ml
Colors available: black, blue, green, orange, purple, red, yellow

Power Supply

100V-240VAC, 50/60HZ, 50W

Air Supply

6 Bar, 90psi, dry, uncontaminated

Operating Temperature

10°-35° C (50°-95° F)

Weight

Unboxed: 3.75kg (8.3lbs); Boxed: 7.4kg (16.3lbs) (single head)

Options

SIMPLCiTY Workflow Modules
Wide range of accessories
